Robotic torsion
Torsion cables for robotic arms, rotary automation, welding dresspacks, cleanroom motion systems and wind turbine nacelle loops where cable twisting, bending, oil exposure and vibration must be specified together.
Torsion cables for robotic arms, rotary automation, welding dresspacks, cleanroom motion systems and wind turbine nacelle loops where cable twisting, bending, oil exposure and vibration must be specified together.
| Motion duty | Continuous robotic torsion, combined bending/torsion, servo-axis motion, cleanroom movement and wind turbine loop torsion |
|---|---|
| Cable function | Control, data, Ethernet, servo power, hybrid dresspack and wind loop circuits |
| Voltage rating | 30 V data circuits, 300 V, 300/500 V and 0.6/1 kV references by cable function |
| Element design | Single conductor, multicore, pair, Ethernet pair and hybrid power/control layouts |
| Screen / protection | Screen-free torsion lay, foil/braid screen, EMC braid, hybrid fillers or support elements by route |
| Jacket | PUR, TPE, HFFR/LSZH or weld-splash resistant compounds selected by motion duty |
| Torsion rating | Torsion angle, guide length, bend radius, travel distance and cycle expectation confirmed before quotation |
| Technical data | Motion duty, cable function, voltage, element design, conductor size, screen/protection, jacket, torsion rating, temperature class, OD guide and cable weight |
Open a cable construction page, then select the voltage, conductor material, core layout and cross-section row that matches your enquiry. Each row opens a cable specification sheet for quote preparation.
Torsion cable pages are organised by robot control, shielded control, data, Ethernet, servo, welding dresspack, cleanroom and wind-loop duty. Open a motion-cable page to compare torsion angle, voltage, element design, conductor size, jacket, OD and weight references.
Robotic PUR Torsion Control Cable is a motion-duty cable reference for industrial robots, rotary tables, machine tools, using class 6 fine-stranded bare copper conductor, screen-free torsion-optimized core assembly, abrasion and oil resistant pur outer jacket and up to +/- 360 degrees per 0.5 m guide.
View technical data →Shielded Robotic PUR Torsion Control Cable is a motion-duty cable reference for robot control loops, servo auxiliary circuits, rotary automation, using class 6 fine-stranded bare copper conductor, tinned copper braid emc screen over torsion-optimized core, abrasion and oil resistant pur outer jacket and up to +/- 360 degrees per 0.5 m guide.
View technical data →Robotic Torsion Data Cable is a motion-duty cable reference for robot sensors, rotating data links, machine vision, using fine-stranded tinned copper data conductor, foil and braid screen for flexible data transmission, low-adhesion pur outer jacket and up to +/- 360 degrees per 0.5 m guide.
View technical data →Torsion Industrial Ethernet Cable is a motion-duty cable reference for robot ethernet, profinet torsion links, machine networks, using fine-stranded tinned copper ethernet conductor, pair screen plus overall braid emc screen, industrial pur ethernet jacket and up to +/- 180 degrees per 1 m guide.
View technical data →Robot Servo Torsion Cable is a motion-duty cable reference for robot servo motors, rotary axes, cnc tool changers, using class 6 fine-stranded bare copper power conductor, overall tinned copper braid emc screen, high-flex pur servo jacket and up to +/- 270 degrees per 0.5 m guide.
View technical data →
Robot dresspack torsion cable
Welding Robot Dresspack Torsion Cable is a motion-duty cable reference for welding robots, dresspack assemblies, robot hose packages, using fine-stranded bare copper hybrid conductor set, hybrid lay with abrasion resistant fillers and optional emc screen, weld-splash and abrasion resistant pur jacket and up to +/- 360 degrees per 0.5 m guide.
View technical data →Cleanroom TPE Torsion Cable is a motion-duty cable reference for cleanroom robots, semiconductor handling, laboratory automation, using fine-stranded tinned copper conductor, optional foil/braid screen with low-particle construction, cleanroom-compatible tpe outer jacket and up to +/- 360 degrees per 0.5 m guide.
View technical data →Wind Turbine Torsion Loop Cable is a motion-duty cable reference for wind turbine nacelle loops, tower yaw loops, converter auxiliary circuits, using class 5 flexible bare copper conductor, optional emc screen or support fillers by loop design, cold, oil and uv resistant hffr / lszh jacket and wind loop torsion up to +/- 150 degrees per m guide.
View technical data →FAQ
Torsion cables for robotic arms, rotary automation, welding dresspacks, cleanroom motion systems and wind turbine nacelle loops where cable twisting, bending, oil exposure and vibration must be specified together. They are built to UL 758, DIN VDE robot cable references, IEC 60228, IEC 60332-1-2, IEC 60754, IEC 61034.
UE Cable torsion cables are manufactured and tested to UL 758, DIN VDE robot cable references, IEC 60228, IEC 60332-1-2, IEC 60754, IEC 61034. The exact standard for each construction is stated on its specification sheet.
8 construction families are catalogued under torsion cables, each offered across a range of conductor sizes and core or pair counts. Open any specification sheet for the exact conductor size, voltage, operating temperature, current rating, overall diameter and weight.
Yes. UE Cable manufactures to customer specification — conductor, insulation, screen, armour, sheath, colour, printing and packing. Send your requirement through the inquiry list and we typically reply within 6 hours with price, lead time and test documentation.
