Fire Resistant Instrumentation Mica LSZH SWA Oil And Gas Cable cable construction reference

Safety-critical fire resistant instrumentation cable

Fire Resistant Instrumentation Mica LSZH SWA Oil And Gas Cable

Fire Resistant Instrumentation Mica LSZH SWA Oil And Gas Cable is an oil, gas and petrochemical cable construction for Emergency shutdown circuits, Fire and gas systems, Offshore safety loops, with IEC 60331 / EN 50288-7, mica fire barrier screened instrumentation cable, individual or overall screen with steel wire armour, circuit integrity fire resistant, lszh and low smoke and orange or blue lszh outer sheath.

Standard
IEC 60331 / EN 50288-7
Voltage class
300/500 V
Conductor
0.75 mm², 1.0 mm², 1.5 mm²
Insulation / jacket
Orange or blue LSZH outer sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Fire Resistant Instrumentation Mica LSZH SWA Oil And Gas Cable is an oil, gas and petrochemical cable construction for Emergency shutdown circuits, Fire and gas systems, Offshore safety loops, with IEC 60331 / EN 50288-7, mica fire barrier screened instrumentation cable, individual or overall screen with steel wire armour, circuit integrity fire resistant, lszh and low smoke and orange or blue lszh outer sheath.

  • Emergency shutdown circuits
  • Fire and gas systems
  • Offshore safety loops
  • Refinery shutdown systems

Cable Construction

  • Mica fire barrier screened instrumentation cable
  • Plain or tinned copper conductor, or optical fibre element where applicable
  • Circuit insulation and identification for oil, gas and petrochemical cable schedules
  • Individual or overall screen with steel wire armour
  • Circuit integrity fire resistant, LSZH and low smoke
  • Orange or blue LSZH outer sheath for emergency shutdown, fire and gas, offshore safety circuits

Specifications

Select a cable size.

Each row below is a complete specification sheet — 15 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Fire Resistant Instrumentation Mica LSZH SWA specification references

Each row is an exact cable specification sheet. Confirm hazardous-area route, cable schedule, fire survival level, oil/mud exposure, gland/accessory package, marking and drum length before quotation.

  • Service packageSafety-critical instrumentation package
  • StandardIEC 60331 / EN 50288-7
  • Cable designMica fire barrier screened instrumentation cable
  • Voltage / signal class300/500 V
  • Screen / protectionIndividual or overall screen with steel wire armour
  • Fire and safety ratingCircuit integrity fire resistant, LSZH and low smoke
  • Oil, mud and environmentEmergency shutdown, fire and gas, offshore safety circuits
  • SheathOrange or blue LSZH outer sheath
Cable referencePair / core designConductor / fibreElectrical / optical referenceOD guide
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 1 pair 0.75 mm² Orange or blue LSZH outer sheath1 pair0.75 mm²24.5 Ω/km max17.3 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 1 pair 1.0 mm² Orange or blue LSZH outer sheath1 pair1.0 mm²18.1 Ω/km max17.5 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 1 pair 1.5 mm² Orange or blue LSZH outer sheath1 pair1.5 mm²12.1 Ω/km max17.9 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 2 pair 0.75 mm² Orange or blue LSZH outer sheath2 pair0.75 mm²24.5 Ω/km max18.1 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 2 pair 1.0 mm² Orange or blue LSZH outer sheath2 pair1.0 mm²18.1 Ω/km max18.3 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 2 pair 1.5 mm² Orange or blue LSZH outer sheath2 pair1.5 mm²12.1 Ω/km max18.7 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 4 pair 0.75 mm² Orange or blue LSZH outer sheath4 pair0.75 mm²24.5 Ω/km max19.2 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 4 pair 1.0 mm² Orange or blue LSZH outer sheath4 pair1.0 mm²18.1 Ω/km max19.4 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 4 pair 1.5 mm² Orange or blue LSZH outer sheath4 pair1.5 mm²12.1 Ω/km max19.8 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 8 pair 0.75 mm² Orange or blue LSZH outer sheath8 pair0.75 mm²24.5 Ω/km max20.8 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 8 pair 1.0 mm² Orange or blue LSZH outer sheath8 pair1.0 mm²18.1 Ω/km max21.0 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 8 pair 1.5 mm² Orange or blue LSZH outer sheath8 pair1.5 mm²12.1 Ω/km max21.4 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 12 pair 0.75 mm² Orange or blue LSZH outer sheath12 pair0.75 mm²24.5 Ω/km max22.0 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 12 pair 1.0 mm² Orange or blue LSZH outer sheath12 pair1.0 mm²18.1 Ω/km max22.2 mm
Fire Resistant Instrumentation Mica LSZH SWA 300/500 V 12 pair 1.5 mm² Orange or blue LSZH outer sheath12 pair1.5 mm²12.1 Ω/km max22.6 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.

Request Quote →
