BS 5308 Armoured Instrumentation Oil And Gas Cable

BS 5308 Armoured Instrumentation Oil And Gas Cable is an oil, gas and petrochemical cable construction for Refinery instrumentation, Petrochemical process control, Tank farm signals, with BS 5308, multipair instrumentation cable, overall aluminium/polyester screen with drain wire and steel wire armour, flame retardant or lszh option and pvc or lszh outer sheath.

Standard
BS 5308
Voltage class
300/500 V
Conductor
0.5 mm², 1.0 mm², 1.5 mm²
Insulation / jacket
PVC or LSZH outer sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

BS 5308 Armoured Instrumentation Oil And Gas Cable is an oil, gas and petrochemical cable construction for Refinery instrumentation, Petrochemical process control, Tank farm signals, with BS 5308, multipair instrumentation cable, overall aluminium/polyester screen with drain wire and steel wire armour, flame retardant or lszh option and pvc or lszh outer sheath.

  • Refinery instrumentation
  • Petrochemical process control
  • Tank farm signals
  • Industrial automation

Cable Construction

  • Multipair instrumentation cable
  • Plain or tinned copper conductor, or optical fibre element where applicable
  • Circuit insulation and identification for oil, gas and petrochemical cable schedules
  • Overall aluminium/polyester screen with drain wire and steel wire armour
  • Flame retardant or LSZH option
  • PVC or LSZH outer sheath for refinery, petrochemical plant and process unit routes

Specifications

Select a cable size.

Each row below is a complete specification sheet — 15 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

BS 5308 Armoured Instrumentation specification references

Each row is an exact cable specification sheet. Confirm hazardous-area route, cable schedule, fire survival level, oil/mud exposure, gland/accessory package, marking and drum length before quotation.

  • Service packageProcess instrumentation and control signal package
  • StandardBS 5308
  • Cable designMultipair instrumentation cable
  • Voltage / signal class300/500 V
  • Screen / protectionOverall aluminium/polyester screen with drain wire and steel wire armour
  • Fire and safety ratingFlame retardant or LSZH option
  • Oil, mud and environmentRefinery, petrochemical plant and process unit routes
  • SheathPVC or LSZH outer sheath
Cable referencePair / core designConductor / fibreElectrical / optical referenceOD guide
BS 5308 Armoured Instrumentation 300/500 V 1 pair 0.5 mm² PVC or LSZH outer sheath1 pair0.5 mm²36.7 Ω/km max17.0 mm
BS 5308 Armoured Instrumentation 300/500 V 1 pair 1.0 mm² PVC or LSZH outer sheath1 pair1.0 mm²18.1 Ω/km max17.5 mm
BS 5308 Armoured Instrumentation 300/500 V 1 pair 1.5 mm² PVC or LSZH outer sheath1 pair1.5 mm²12.1 Ω/km max17.9 mm
BS 5308 Armoured Instrumentation 300/500 V 2 pair 0.5 mm² PVC or LSZH outer sheath2 pair0.5 mm²36.7 Ω/km max17.8 mm
BS 5308 Armoured Instrumentation 300/500 V 2 pair 1.0 mm² PVC or LSZH outer sheath2 pair1.0 mm²18.1 Ω/km max18.3 mm
BS 5308 Armoured Instrumentation 300/500 V 2 pair 1.5 mm² PVC or LSZH outer sheath2 pair1.5 mm²12.1 Ω/km max18.7 mm
BS 5308 Armoured Instrumentation 300/500 V 5 pair 0.5 mm² PVC or LSZH outer sheath5 pair0.5 mm²36.7 Ω/km max19.4 mm
BS 5308 Armoured Instrumentation 300/500 V 5 pair 1.0 mm² PVC or LSZH outer sheath5 pair1.0 mm²18.1 Ω/km max19.9 mm
BS 5308 Armoured Instrumentation 300/500 V 5 pair 1.5 mm² PVC or LSZH outer sheath5 pair1.5 mm²12.1 Ω/km max20.2 mm
BS 5308 Armoured Instrumentation 300/500 V 10 pair 0.5 mm² PVC or LSZH outer sheath10 pair0.5 mm²36.7 Ω/km max21.2 mm
BS 5308 Armoured Instrumentation 300/500 V 10 pair 1.0 mm² PVC or LSZH outer sheath10 pair1.0 mm²18.1 Ω/km max21.6 mm
BS 5308 Armoured Instrumentation 300/500 V 10 pair 1.5 mm² PVC or LSZH outer sheath10 pair1.5 mm²12.1 Ω/km max22.0 mm
BS 5308 Armoured Instrumentation 300/500 V 20 pair 0.5 mm² PVC or LSZH outer sheath20 pair0.5 mm²36.7 Ω/km max23.7 mm
BS 5308 Armoured Instrumentation 300/500 V 20 pair 1.0 mm² PVC or LSZH outer sheath20 pair1.0 mm²18.1 Ω/km max24.1 mm
BS 5308 Armoured Instrumentation 300/500 V 20 pair 1.5 mm² PVC or LSZH outer sheath20 pair1.5 mm²12.1 Ω/km max24.5 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.

Request Quote →
