Medium Voltage Mining Feeder Cable cable construction reference

MV mining feeder cable

Medium Voltage Mining Feeder Cable

Medium Voltage Mining Feeder Cable is a specific mining cable construction for mine power distribution, continuous miners, longwall supply applications, using flexible tinned copper conductor, epr insulation, semiconductive and metallic screen system and heavy-duty mining sheath.

Standard
AS/NZS 1802
Voltage class
3.3/3.3 kV to 11/11 kV
Conductor
Flexible tinned copper conductor
Insulation / jacket
Heavy-duty mining sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Medium Voltage Mining Feeder Cable is a specific mining cable construction for mine power distribution, continuous miners, longwall supply applications, using flexible tinned copper conductor, epr insulation, semiconductive and metallic screen system and heavy-duty mining sheath.

  • Mine power distribution
  • Continuous miners
  • Longwall supply
  • Substation feeders

Cable Construction

  • Flexible tinned copper conductor
  • EPR insulation
  • Semiconductive and metallic screen system
  • Earth continuity or pilot core arrangement according to equipment
  • Heavy-duty mining sheath

Specifications

Select a cable size.

Each row below is a complete specification sheet — 18 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

3.3/3.3 kV specification references

Each row is an exact mining cable cable specification sheet. Shared standard, compound and duty notes are listed above.

  • Voltage class3.3/3.3 kV
  • Equipment dutyMine feeder
  • Core / pilot design3 power cores + earth + pilot
Cable referenceConductor sizeMax DC resistance at 20 °COD guide
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 25 mm²25 mm²0.780 Ω/km29 mm
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 35 mm²35 mm²0.554 Ω/km31 mm
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 50 mm²50 mm²0.386 Ω/km34 mm
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 70 mm²70 mm²0.272 Ω/km37 mm
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 95 mm²95 mm²0.206 Ω/km40 mm
MV mining feeder cable 3.3/3.3 kV Mine feeder 3 power cores + earth + pilot 120 mm²120 mm²0.161 Ω/km43 mm

6.6/6.6 kV specification references

Each row is an exact mining cable cable specification sheet. Shared standard, compound and duty notes are listed above.

  • Voltage class6.6/6.6 kV
  • Equipment dutyContinuous miner
  • Core / pilot design3 power cores + earth + pilot
Cable referenceConductor sizeMax DC resistance at 20 °COD guide
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 35 mm²35 mm²0.554 Ω/km35 mm
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 50 mm²50 mm²0.386 Ω/km38 mm
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 70 mm²70 mm²0.272 Ω/km41 mm
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 95 mm²95 mm²0.206 Ω/km44 mm
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 120 mm²120 mm²0.161 Ω/km47 mm
MV mining feeder cable 6.6/6.6 kV Continuous miner 3 power cores + earth + pilot 150 mm²150 mm²0.129 Ω/km50 mm

11/11 kV specification references

Each row is an exact mining cable cable specification sheet. Shared standard, compound and duty notes are listed above.

  • Voltage class11/11 kV
  • Equipment dutyLongwall supply
  • Core / pilot design3 power cores + earth + pilot
Cable referenceConductor sizeMax DC resistance at 20 °COD guide
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 50 mm²50 mm²0.386 Ω/km42 mm
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 70 mm²70 mm²0.272 Ω/km45 mm
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 95 mm²95 mm²0.206 Ω/km48 mm
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 120 mm²120 mm²0.161 Ω/km51 mm
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 150 mm²150 mm²0.129 Ω/km54 mm
MV mining feeder cable 11/11 kV Longwall supply 3 power cores + earth + pilot 185 mm²185 mm²0.106 Ω/km58 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.

Request Quote →
