Glass Fiber High Temperature Thermocouple Cable cable construction reference

Glass fiber high-temperature thermocouple cable

Glass Fiber High Temperature Thermocouple Cable

Glass Fiber High Temperature Thermocouple Cable is a thermocouple cable reference for heat treatment, furnaces, metal processing, using KX, JX, TX thermocouple alloy conductors, glass fiber insulated conductors with glass fiber outer braid and screen-free flat or twisted high-temperature pair.

Standard: IEC 60584-3 / ANSI MC96.1
Voltage class: Instrumentation signal circuit
Temperature class: Up to +480 °C continuous route guide
Conductor: 1/0.2 mm solid / 32 AWG, 1/0.3 mm solid / 28 AWG, 1/0.5 mm solid / 24 AWG, 7/0.2 mm stranded / 24 AWG
Insulation / jacket: Varnished glass fiber braid

Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Glass Fiber High Temperature Thermocouple Cable is a thermocouple cable reference for heat treatment, furnaces, metal processing, using KX, JX, TX thermocouple alloy conductors, glass fiber insulated conductors with glass fiber outer braid and screen-free flat or twisted high-temperature pair.

Heat treatment
Furnaces
Metal processing
High-temperature test benches

Cable Construction

Thermocouple alloy positive and negative conductors
Extension grade for KX, JX, TX circuits
Glass fiber insulated conductors with glass fiber outer braid
Screen-free flat or twisted high-temperature pair
Varnished glass fiber braid

Specifications

Select a cable size.

Each row below is a complete specification sheet — 12 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Glass fiber high temperature thermocouple cable specification references

Each row is an exact thermocouple cable cable specification sheet.

Cable gradeExtension grade
Pair layout1 pair
Insulation / sheathGlass fiber insulated conductors with glass fiber outer braid
Screen / protectionScreen-free flat or twisted high-temperature pair
Temperature rangeUp to +480 °C continuous route guide
Tolerance classIEC 60584-3 Class 1 / Class 2 option

Cable reference	Thermocouple type	Conductor construction	Alloy combination	OD guide
Glass fiber high temperature thermocouple cable KX 1 pair 1/0.2 mm solid / 32 AWG	KX	1/0.2 mm solid / 32 AWG	Positive NiCr / negative NiAl	8.7 mm
Glass fiber high temperature thermocouple cable KX 1 pair 1/0.3 mm solid / 28 AWG	KX	1/0.3 mm solid / 28 AWG	Positive NiCr / negative NiAl	8.8 mm
Glass fiber high temperature thermocouple cable KX 1 pair 1/0.5 mm solid / 24 AWG	KX	1/0.5 mm solid / 24 AWG	Positive NiCr / negative NiAl	9.0 mm
Glass fiber high temperature thermocouple cable KX 1 pair 7/0.2 mm stranded / 24 AWG	KX	7/0.2 mm stranded / 24 AWG	Positive NiCr / negative NiAl	9.2 mm
Glass fiber high temperature thermocouple cable JX 1 pair 1/0.2 mm solid / 32 AWG	JX	1/0.2 mm solid / 32 AWG	Positive iron / negative constantan	8.7 mm
Glass fiber high temperature thermocouple cable JX 1 pair 1/0.3 mm solid / 28 AWG	JX	1/0.3 mm solid / 28 AWG	Positive iron / negative constantan	8.8 mm
Glass fiber high temperature thermocouple cable JX 1 pair 1/0.5 mm solid / 24 AWG	JX	1/0.5 mm solid / 24 AWG	Positive iron / negative constantan	9.0 mm
Glass fiber high temperature thermocouple cable JX 1 pair 7/0.2 mm stranded / 24 AWG	JX	7/0.2 mm stranded / 24 AWG	Positive iron / negative constantan	9.2 mm
Glass fiber high temperature thermocouple cable TX 1 pair 1/0.2 mm solid / 32 AWG	TX	1/0.2 mm solid / 32 AWG	Positive copper / negative constantan	8.7 mm
Glass fiber high temperature thermocouple cable TX 1 pair 1/0.3 mm solid / 28 AWG	TX	1/0.3 mm solid / 28 AWG	Positive copper / negative constantan	8.8 mm
Glass fiber high temperature thermocouple cable TX 1 pair 1/0.5 mm solid / 24 AWG	TX	1/0.5 mm solid / 24 AWG	Positive copper / negative constantan	9.0 mm
Glass fiber high temperature thermocouple cable TX 1 pair 7/0.2 mm stranded / 24 AWG	TX	7/0.2 mm stranded / 24 AWG	Positive copper / negative constantan	9.2 mm

Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
