Type TX PVC Overall Screened Thermocouple Extension Cable cable construction reference

Screened Type T extension cable

Type TX PVC Overall Screened Thermocouple Extension Cable

Type TX PVC Overall Screened Thermocouple Extension Cable is a thermocouple cable reference for low-temperature measurement, laboratory systems, food and cold-chain instrumentation, using TX thermocouple alloy conductors, flame retardant pvc thermocouple insulation and al/pet overall tape screen with tinned copper drain wire.

Standard: IEC 60584-3
Voltage class: 250 V instrumentation circuit
Temperature class: -20 °C to +60 °C cable route
Conductor: 1/0.5 mm solid / 24 AWG, 7/0.2 mm stranded / 24 AWG
Insulation / jacket: FR PVC outer sheath

Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Type TX PVC Overall Screened Thermocouple Extension Cable is a thermocouple cable reference for low-temperature measurement, laboratory systems, food and cold-chain instrumentation, using TX thermocouple alloy conductors, flame retardant pvc thermocouple insulation and al/pet overall tape screen with tinned copper drain wire.

Low-temperature measurement
Laboratory systems
Food and cold-chain instrumentation
Process control

Cable Construction

Thermocouple alloy positive and negative conductors
Extension grade for TX circuits
Flame retardant PVC thermocouple insulation
Al/PET overall tape screen with tinned copper drain wire
FR PVC outer sheath

Specifications

Select a cable size.

Each row below is a complete specification sheet — 8 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Type TX PVC overall screened thermocouple extension cable specification references

Each row is an exact thermocouple cable cable specification sheet.

Thermocouple typeTX
Cable gradeExtension grade
Alloy combinationPositive copper / negative constantan
Insulation / sheathFlame retardant PVC thermocouple insulation
Screen / protectionAl/PET overall tape screen with tinned copper drain wire
Temperature range-20 °C to +60 °C cable route
Tolerance classIEC 60584-3 Class 1 / Class 2 option

Cable reference	Pair layout	Conductor construction	OD guide
Type TX PVC overall screened thermocouple extension cable TX 1 pair 1/0.5 mm solid / 24 AWG	1 pair	1/0.5 mm solid / 24 AWG	8.2 mm
Type TX PVC overall screened thermocouple extension cable TX 1 pair 7/0.2 mm stranded / 24 AWG	1 pair	7/0.2 mm stranded / 24 AWG	8.4 mm
Type TX PVC overall screened thermocouple extension cable TX 2 pair 1/0.5 mm solid / 24 AWG	2 pair	1/0.5 mm solid / 24 AWG	9.3 mm
Type TX PVC overall screened thermocouple extension cable TX 2 pair 7/0.2 mm stranded / 24 AWG	2 pair	7/0.2 mm stranded / 24 AWG	9.5 mm
Type TX PVC overall screened thermocouple extension cable TX 4 pair 1/0.5 mm solid / 24 AWG	4 pair	1/0.5 mm solid / 24 AWG	10.8 mm
Type TX PVC overall screened thermocouple extension cable TX 4 pair 7/0.2 mm stranded / 24 AWG	4 pair	7/0.2 mm stranded / 24 AWG	11.0 mm
Type TX PVC overall screened thermocouple extension cable TX 8 pair 1/0.5 mm solid / 24 AWG	8 pair	1/0.5 mm solid / 24 AWG	13.0 mm
Type TX PVC overall screened thermocouple extension cable TX 8 pair 7/0.2 mm stranded / 24 AWG	8 pair	7/0.2 mm stranded / 24 AWG	13.1 mm

Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
