PVC Flat Festoon Crane Cable

PVC Flat Festoon Crane Cable is a crane cable construction for indoor overhead cranes, festoon systems, hoists, using flexible copper conductor, flexible pvc core insulation, flat stacked cable layout and pvc flat outer sheath.

Standard: DIN VDE 0250
Voltage class: 300/500 V
Conductor: Flexible copper conductor
Insulation / jacket: PVC flat outer sheath

Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Indoor overhead cranes
Festoon systems
Hoists
Conveyors

Cable Construction

Flexible copper conductor
Flexible PVC core insulation
Flat stacked cable layout
PVC flat outer sheath

Specifications

Select a cable size.

Each row below is a complete specification sheet — 20 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

PVC flat festoon cable references

Each row is an exact crane cable cable specification sheet. Shared motion duty, voltage, materials and mechanical requirements are listed above.

Motion dutyIndoor festoon and trolley movement
Cable systemFlat festoon cable

Cable reference	Core design	Conductor size	Max DC resistance at 20 °C	Dimension guide	Cable weight
PVC flat festoon crane cable 300/500 V Flat festoon cable 4 core flat 0.75 mm²	4 core flat	0.75 mm²	24.7 Ω/km	24 x 6.7 mm	0.31 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 4 core flat 1.0 mm²	4 core flat	1.0 mm²	18.5 Ω/km	25 x 6.8 mm	0.32 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 4 core flat 1.5 mm²	4 core flat	1.5 mm²	12.7 Ω/km	26 x 7.1 mm	0.34 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 4 core flat 2.5 mm²	4 core flat	2.5 mm²	7.6 Ω/km	28 x 7.5 mm	0.39 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 8 core flat 0.75 mm²	8 core flat	0.75 mm²	24.7 Ω/km	47 x 6.7 mm	0.34 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 8 core flat 1.0 mm²	8 core flat	1.0 mm²	18.5 Ω/km	49 x 6.8 mm	0.37 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 8 core flat 1.5 mm²	8 core flat	1.5 mm²	12.7 Ω/km	51 x 7.1 mm	0.41 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 8 core flat 2.5 mm²	8 core flat	2.5 mm²	7.6 Ω/km	55 x 7.5 mm	0.51 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 12 core flat 0.75 mm²	12 core flat	0.75 mm²	24.7 Ω/km	71 x 6.7 mm	0.38 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 12 core flat 1.0 mm²	12 core flat	1.0 mm²	18.5 Ω/km	73 x 6.8 mm	0.41 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 12 core flat 1.5 mm²	12 core flat	1.5 mm²	12.7 Ω/km	77 x 7.1 mm	0.49 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 12 core flat 2.5 mm²	12 core flat	2.5 mm²	7.6 Ω/km	83 x 7.5 mm	0.63 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 18 core flat 0.75 mm²	18 core flat	0.75 mm²	24.7 Ω/km	105 x 6.7 mm	0.43 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 18 core flat 1.0 mm²	18 core flat	1.0 mm²	18.5 Ω/km	109 x 6.8 mm	0.49 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 18 core flat 1.5 mm²	18 core flat	1.5 mm²	12.7 Ω/km	114 x 7.1 mm	0.59 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 18 core flat 2.5 mm²	18 core flat	2.5 mm²	7.6 Ω/km	123 x 7.5 mm	0.81 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 24 core flat 0.75 mm²	24 core flat	0.75 mm²	24.7 Ω/km	140 x 6.7 mm	0.49 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 24 core flat 1.0 mm²	24 core flat	1.0 mm²	18.5 Ω/km	145 x 6.8 mm	0.56 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 24 core flat 1.5 mm²	24 core flat	1.5 mm²	12.7 Ω/km	152 x 7.1 mm	0.70 kg/m
PVC flat festoon crane cable 300/500 V Flat festoon cable 24 core flat 2.5 mm²	24 core flat	2.5 mm²	7.6 Ω/km	164 x 7.5 mm	0.99 kg/m

Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
