Neoprene Flat Festoon Crane Cable cable construction reference

Outdoor flat festoon crane cable

Neoprene Flat Festoon Crane Cable

Neoprene Flat Festoon Crane Cable is a crane cable construction for outdoor cranes, port handling, festoon systems, using flexible copper conductor, epr rubber insulation, flat stacked cable layout and neoprene rubber flat sheath.

Standard
DIN VDE 0250
Voltage class
450/750 V
Conductor
Flexible copper conductor
Insulation / jacket
Neoprene rubber flat sheath

Cable Type Data

Construction and applications.

Applications

Neoprene Flat Festoon Crane Cable is a crane cable construction for outdoor cranes, port handling, festoon systems, using flexible copper conductor, epr rubber insulation, flat stacked cable layout and neoprene rubber flat sheath.

  • Outdoor cranes
  • Port handling
  • Festoon systems
  • Material handling

Cable Construction

  • Flexible copper conductor
  • EPR rubber insulation
  • Flat stacked cable layout
  • Neoprene rubber flat sheath

Specifications

Select a cable size.

Each row below is a complete specification sheet — 20 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Neoprene flat festoon cable references

Each row is an exact crane cable cable specification sheet. Shared motion duty, voltage, materials and mechanical requirements are listed above.

  • Motion dutyOutdoor festoon and trolley movement
  • Cable systemFlat festoon cable
Cable referenceCore designConductor sizeMax DC resistance at 20 °CDimension guideCable weight
NEO flat festoon crane cable 450/750 V Flat festoon cable 4 core flat 1.5 mm²4 core flat1.5 mm²12.7 Ω/km26 x 7.1 mm0.34 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 4 core flat 2.5 mm²4 core flat2.5 mm²7.6 Ω/km28 x 7.5 mm0.39 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 4 core flat 4 mm²4 core flat4 mm²4.7 Ω/km30 x 8.0 mm0.46 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 4 core flat 6 mm²4 core flat6 mm²3.1 Ω/km33 x 8.6 mm0.56 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 8 core flat 1.5 mm²8 core flat1.5 mm²12.7 Ω/km51 x 7.1 mm0.41 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 8 core flat 2.5 mm²8 core flat2.5 mm²7.6 Ω/km55 x 7.5 mm0.51 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 8 core flat 4 mm²8 core flat4 mm²4.7 Ω/km60 x 8.0 mm0.65 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 8 core flat 6 mm²8 core flat6 mm²3.1 Ω/km65 x 8.6 mm0.85 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 12 core flat 1.5 mm²12 core flat1.5 mm²12.7 Ω/km77 x 7.1 mm0.49 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 12 core flat 2.5 mm²12 core flat2.5 mm²7.6 Ω/km83 x 7.5 mm0.63 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 12 core flat 4 mm²12 core flat4 mm²4.7 Ω/km90 x 8.0 mm0.85 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 12 core flat 6 mm²12 core flat6 mm²3.1 Ω/km97 x 8.6 mm1.13 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 18 core flat 1.5 mm²18 core flat1.5 mm²12.7 Ω/km114 x 7.1 mm0.59 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 18 core flat 2.5 mm²18 core flat2.5 mm²7.6 Ω/km123 x 7.5 mm0.81 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 18 core flat 4 mm²18 core flat4 mm²4.7 Ω/km134 x 8.0 mm1.13 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 18 core flat 6 mm²18 core flat6 mm²3.1 Ω/km145 x 8.6 mm1.57 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 24 core flat 1.5 mm²24 core flat1.5 mm²12.7 Ω/km152 x 7.1 mm0.70 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 24 core flat 2.5 mm²24 core flat2.5 mm²7.6 Ω/km164 x 7.5 mm0.99 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 24 core flat 4 mm²24 core flat4 mm²4.7 Ω/km178 x 8.0 mm1.42 kg/m
NEO flat festoon crane cable 450/750 V Flat festoon cable 24 core flat 6 mm²24 core flat6 mm²3.1 Ω/km194 x 8.6 mm2.00 kg/m
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
