Glass Fiber Stainless Steel Overbraid Thermocouple Cable cable construction reference

Mechanically protected high-temperature thermocouple cable

Glass Fiber Stainless Steel Overbraid Thermocouple Cable

Glass Fiber Stainless Steel Overbraid Thermocouple Cable is a thermocouple cable reference for furnace zones, hot machinery, abrasive high-temperature routes, using KX, JX, TX thermocouple alloy conductors, glass fiber insulated conductors with glass fiber inner jacket and stainless steel overbraid mechanical protection.

Standard
IEC 60584-3 / ANSI MC96.1
Voltage class
Instrumentation signal circuit
Temperature class
Up to +400 °C route guide
Conductor
1/0.3 mm solid / 28 AWG, 7/0.2 mm stranded / 24 AWG
Insulation / jacket
Stainless steel overbraid over glass fiber jacket
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Glass Fiber Stainless Steel Overbraid Thermocouple Cable is a thermocouple cable reference for furnace zones, hot machinery, abrasive high-temperature routes, using KX, JX, TX thermocouple alloy conductors, glass fiber insulated conductors with glass fiber inner jacket and stainless steel overbraid mechanical protection.

  • Furnace zones
  • Hot machinery
  • Abrasive high-temperature routes
  • Heat treatment equipment

Cable Construction

  • Thermocouple alloy positive and negative conductors
  • Extension grade for KX, JX, TX circuits
  • Glass fiber insulated conductors with glass fiber inner jacket
  • Stainless steel overbraid mechanical protection
  • Stainless steel overbraid over glass fiber jacket

Specifications

Select a cable size.

Each row below is a complete specification sheet — 12 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Glass fiber stainless steel overbraid thermocouple cable specification references

Each row is an exact thermocouple cable cable specification sheet.

  • Cable gradeExtension grade
  • Insulation / sheathGlass fiber insulated conductors with glass fiber inner jacket
  • Screen / protectionStainless steel overbraid mechanical protection
  • Temperature rangeUp to +400 °C route guide
  • Tolerance classIEC 60584-3 Class 1 / Class 2 option
Cable referenceThermocouple typePair layoutConductor constructionAlloy combinationOD guide
Glass fiber stainless steel overbraid thermocouple cable KX 1 pair 1/0.3 mm solid / 28 AWGKX1 pair1/0.3 mm solid / 28 AWGPositive NiCr / negative NiAl8.8 mm
Glass fiber stainless steel overbraid thermocouple cable KX 1 pair 7/0.2 mm stranded / 24 AWGKX1 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl9.2 mm
Glass fiber stainless steel overbraid thermocouple cable KX 2 pair 1/0.3 mm solid / 28 AWGKX2 pair1/0.3 mm solid / 28 AWGPositive NiCr / negative NiAl9.9 mm
Glass fiber stainless steel overbraid thermocouple cable KX 2 pair 7/0.2 mm stranded / 24 AWGKX2 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl10.3 mm
Glass fiber stainless steel overbraid thermocouple cable JX 1 pair 1/0.3 mm solid / 28 AWGJX1 pair1/0.3 mm solid / 28 AWGPositive iron / negative constantan8.8 mm
Glass fiber stainless steel overbraid thermocouple cable JX 1 pair 7/0.2 mm stranded / 24 AWGJX1 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan9.2 mm
Glass fiber stainless steel overbraid thermocouple cable JX 2 pair 1/0.3 mm solid / 28 AWGJX2 pair1/0.3 mm solid / 28 AWGPositive iron / negative constantan9.9 mm
Glass fiber stainless steel overbraid thermocouple cable JX 2 pair 7/0.2 mm stranded / 24 AWGJX2 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan10.3 mm
Glass fiber stainless steel overbraid thermocouple cable TX 1 pair 1/0.3 mm solid / 28 AWGTX1 pair1/0.3 mm solid / 28 AWGPositive copper / negative constantan8.8 mm
Glass fiber stainless steel overbraid thermocouple cable TX 1 pair 7/0.2 mm stranded / 24 AWGTX1 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan9.2 mm
Glass fiber stainless steel overbraid thermocouple cable TX 2 pair 1/0.3 mm solid / 28 AWGTX2 pair1/0.3 mm solid / 28 AWGPositive copper / negative constantan9.9 mm
Glass fiber stainless steel overbraid thermocouple cable TX 2 pair 7/0.2 mm stranded / 24 AWGTX2 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan10.3 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.

Request Quote →
