Signal reference cable
3082A Style 22 AWG 1 Pair Low Capacitance Data Cable
22 AWG one-pair low-capacitance data cable references for balanced data, control and signal circuits requiring foil shielding.
- Standard
- Data signal cable reference
- Conductor
- 22 AWG stranded tinned copper
- Insulation / jacket
- PVC, LSZH or outdoor jacket option
Cable Type Data
Construction and applications.
Cable Construction
- 22 AWG stranded tinned copper
- Foam PE or PE insulation
- Overall foil shield with drain wire
- PVC, LSZH or outdoor jacket option outer jacket
- Electrical reference data confirmed by conductor resistance, capacitance, impedance and voltage class
Specifications
Select a cable size.
Each row below is a complete specification sheet — 4 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
3082A Style 22 AWG 1 Pair Low Capacitance Data Cable Specification References
Select the exact signal reference by circuit type, conductor, shield, capacitance, impedance, jacket and voltage class. Each row opens a cable specification sheet for quotation.
- Reference style3082A style
- Pair / core layout1 pair
- Conductor22 AWG 7/30 tinned copper
- Conductor resistance18.2 Ω/1000 ft nominal
- Screen / shieldOverall foil shield + drain wire
- CapacitanceLow-capacitance data reference
- ImpedanceBalanced data reference
- Voltage class300 V
| Cable reference | Circuit type | Jacket |
|---|---|---|
| 3082A style 22 AWG 1 pair PVC CM low capacitance data cable | Indoor data/control | PVC CM |
| 3082A style 22 AWG 1 pair Low-smoke jacket low capacitance data cable | Building data route | Low-smoke jacket |
| 3082A style 22 AWG 1 pair Outdoor PE jacket low capacitance data cable | Protected outdoor data route | Outdoor PE jacket |
| 3082A style 22 AWG 1 pair Plenum jacket low capacitance data cable | Air-handling signal route | Plenum jacket |
Cable Specification Sheets
Exact cable references by conductor size and construction.
Request Quote →
Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
