8760 Style 18 AWG 1 Pair Shielded Signal Cable

18 AWG one-pair shielded signal cable references for analogue signal, audio, control and panel wiring circuits where low capacitance and foil shielding are required.

Standard: CM / UL AWM style signal cable reference
Conductor: 18 AWG stranded tinned copper
Insulation / jacket: PVC or low-smoke jacket option

Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

18 AWG one-pair shielded signal cable references for analogue signal, audio, control and panel wiring circuits where low capacitance and foil shielding are required.

Analogue signals
Low-voltage digital control
Line-level audio
Computer communication
Panel wiring

Cable Construction

18 AWG stranded tinned copper
PE insulation
Overall aluminium-polyester foil shield with tinned copper drain wire
PVC or low-smoke jacket option outer jacket
Electrical reference data confirmed by conductor resistance, capacitance, impedance and voltage class

Specifications

Select a cable size.

Each row below is a complete specification sheet — 4 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
