Applications
22 AWG multi-pair overall shielded control cable references for instrumentation, panel wiring and low-voltage interconnect circuits.
- Control panels
- Instrumentation interconnect
- Low-voltage signal
- Building control
- OEM wiring
Signal reference cable
Multi-Pair 22 AWG Overall Shielded Control Reference Cable
22 AWG multi-pair overall shielded control cable references for instrumentation, panel wiring and low-voltage interconnect circuits.
- Standard
- Multi-pair signal cable reference
- Conductor
- 22 AWG stranded tinned copper
- Insulation / jacket
- PVC or LSZH jacket option
Cable Type Data
Construction and applications.
Cable Construction
- 22 AWG stranded tinned copper
- PE or PP insulation
- Overall foil shield with drain wire
- PVC or LSZH jacket option outer jacket
- Electrical reference data confirmed by conductor resistance, capacitance, impedance and voltage class
Specifications
Select a cable size.
Each row below is a complete specification sheet — 4 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
Multi-Pair 22 AWG Overall Shielded Control Reference Cable Specification References
Select the exact signal reference by circuit type, conductor, shield, capacitance, impedance, jacket and voltage class. Each row opens a cable specification sheet for quotation.
- Reference style22 AWG multi-pair
- Circuit typeControl and instrumentation
- Conductor22 AWG stranded tinned copper
- Conductor resistance18.2 Ω/1000 ft nominal
- Screen / shieldOverall foil shield + drain wire
- CapacitanceLow-capacitance multi-pair reference
- ImpedanceSignal control reference
- Voltage class300 V reference
| Cable reference | Pair / core layout | Jacket |
|---|---|---|
| 2 pair 22 AWG overall shielded control reference cable | 2 pair | PVC jacket |
| 3 pair 22 AWG overall shielded control reference cable | 3 pair | PVC jacket |
| 4 pair 22 AWG overall shielded control reference cable | 4 pair | PVC jacket |
| 6 pair 22 AWG overall shielded control reference cable | 6 pair | LSZH jacket |
Cable Specification Sheets
Exact cable references by conductor size and construction.
Request Quote →
Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
