EV charging infrastructure bus cable
EVC Flat Power Bus LSZH Cable is an electric vehicle charging cable construction for parking garage charging infrastructure, multi-bay ev charging, commercial buildings applications, using flexible copper conductors, xlpe insulation, lszh polyolefin sheath and indoor parking, low smoke and expandable charging infrastructure duty.
Cable Type Data
EVC Flat Power Bus LSZH Cable is an electric vehicle charging cable construction for parking garage charging infrastructure, multi-bay ev charging, commercial buildings applications, using flexible copper conductors, xlpe insulation, lszh polyolefin sheath and indoor parking, low smoke and expandable charging infrastructure duty.
Specifications
Each row below is a complete specification sheet — 4 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
Each row is an exact cable specification sheet. Confirm connector type, cable length and operating current before quotation.
| Cable reference | Current guide | Power conductor | OD guide |
|---|---|---|---|
| EVC Flat Power Bus LSZH EV charging infrastructure bus cable 63 A 5 core flat 16 mm² | 63 A | 16 mm² | 27 mm |
| EVC Flat Power Bus LSZH EV charging infrastructure bus cable 80 A 5 core flat 25 mm² | 80 A | 25 mm² | 30 mm |
| EVC Flat Power Bus LSZH EV charging infrastructure bus cable 100 A 5 core flat 35 mm² | 100 A | 35 mm² | 32 mm |
| EVC Flat Power Bus LSZH EV charging infrastructure bus cable 125 A 5 core flat 50 mm² | 125 A | 50 mm² | 35 mm |
Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
