Multipair Screened Thermocouple Instrumentation Cable cable construction reference

Multipair screened thermocouple cable

Multipair Screened Thermocouple Instrumentation Cable

Multipair Screened Thermocouple Instrumentation Cable is a thermocouple cable reference for process plants, temperature marshalling cabinets, control rooms, using KX, JX, TX thermocouple alloy conductors, PVC thermocouple pair insulation and individual pair screen plus overall tape screen with drain wire.

Standard
IEC 60584-3 / IEC 60332-1-2
Voltage class
250 V instrumentation circuit
Temperature class
-20 °C to +70 °C cable route
Conductor
1/0.5 mm solid / 24 AWG, 7/0.2 mm stranded / 24 AWG
Insulation / jacket
PVC outer sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Multipair Screened Thermocouple Instrumentation Cable is a thermocouple cable reference for process plants, temperature marshalling cabinets, control rooms, using KX, JX, TX thermocouple alloy conductors, PVC thermocouple pair insulation and individual pair screen plus overall tape screen with drain wire.

  • Process plants
  • Temperature marshalling cabinets
  • Control rooms
  • Industrial instrumentation

Cable Construction

  • Thermocouple alloy positive and negative conductors
  • Extension grade for KX, JX, TX circuits
  • PVC thermocouple pair insulation
  • Individual pair screen plus overall tape screen with drain wire
  • PVC outer sheath

Specifications

Select a cable size.

Each row below is a complete specification sheet — 30 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Multipair screened thermocouple instrumentation cable specification references

Each row is an exact thermocouple cable cable specification sheet.

  • Cable gradeExtension grade
  • Insulation / sheathPVC thermocouple pair insulation
  • Screen / protectionIndividual pair screen plus overall tape screen with drain wire
  • Temperature range-20 °C to +70 °C cable route
  • Tolerance classIEC 60584-3 Class 1 / Class 2 option
Cable referenceThermocouple typePair layoutConductor constructionAlloy combinationOD guide
Multipair screened thermocouple instrumentation cable KX 2 pair 1/0.5 mm solid / 24 AWGKX2 pair1/0.5 mm solid / 24 AWGPositive NiCr / negative NiAl9.3 mm
Multipair screened thermocouple instrumentation cable KX 2 pair 7/0.2 mm stranded / 24 AWGKX2 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl9.5 mm
Multipair screened thermocouple instrumentation cable KX 4 pair 1/0.5 mm solid / 24 AWGKX4 pair1/0.5 mm solid / 24 AWGPositive NiCr / negative NiAl10.8 mm
Multipair screened thermocouple instrumentation cable KX 4 pair 7/0.2 mm stranded / 24 AWGKX4 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl11.0 mm
Multipair screened thermocouple instrumentation cable KX 8 pair 1/0.5 mm solid / 24 AWGKX8 pair1/0.5 mm solid / 24 AWGPositive NiCr / negative NiAl13.0 mm
Multipair screened thermocouple instrumentation cable KX 8 pair 7/0.2 mm stranded / 24 AWGKX8 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl13.1 mm
Multipair screened thermocouple instrumentation cable KX 12 pair 1/0.5 mm solid / 24 AWGKX12 pair1/0.5 mm solid / 24 AWGPositive NiCr / negative NiAl14.7 mm
Multipair screened thermocouple instrumentation cable KX 12 pair 7/0.2 mm stranded / 24 AWGKX12 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl14.8 mm
Multipair screened thermocouple instrumentation cable KX 24 pair 1/0.5 mm solid / 24 AWGKX24 pair1/0.5 mm solid / 24 AWGPositive NiCr / negative NiAl18.4 mm
Multipair screened thermocouple instrumentation cable KX 24 pair 7/0.2 mm stranded / 24 AWGKX24 pair7/0.2 mm stranded / 24 AWGPositive NiCr / negative NiAl18.5 mm
Multipair screened thermocouple instrumentation cable JX 2 pair 1/0.5 mm solid / 24 AWGJX2 pair1/0.5 mm solid / 24 AWGPositive iron / negative constantan9.3 mm
Multipair screened thermocouple instrumentation cable JX 2 pair 7/0.2 mm stranded / 24 AWGJX2 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan9.5 mm
Multipair screened thermocouple instrumentation cable JX 4 pair 1/0.5 mm solid / 24 AWGJX4 pair1/0.5 mm solid / 24 AWGPositive iron / negative constantan10.8 mm
Multipair screened thermocouple instrumentation cable JX 4 pair 7/0.2 mm stranded / 24 AWGJX4 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan11.0 mm
Multipair screened thermocouple instrumentation cable JX 8 pair 1/0.5 mm solid / 24 AWGJX8 pair1/0.5 mm solid / 24 AWGPositive iron / negative constantan13.0 mm
Multipair screened thermocouple instrumentation cable JX 8 pair 7/0.2 mm stranded / 24 AWGJX8 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan13.1 mm
Multipair screened thermocouple instrumentation cable JX 12 pair 1/0.5 mm solid / 24 AWGJX12 pair1/0.5 mm solid / 24 AWGPositive iron / negative constantan14.7 mm
Multipair screened thermocouple instrumentation cable JX 12 pair 7/0.2 mm stranded / 24 AWGJX12 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan14.8 mm
Multipair screened thermocouple instrumentation cable JX 24 pair 1/0.5 mm solid / 24 AWGJX24 pair1/0.5 mm solid / 24 AWGPositive iron / negative constantan18.4 mm
Multipair screened thermocouple instrumentation cable JX 24 pair 7/0.2 mm stranded / 24 AWGJX24 pair7/0.2 mm stranded / 24 AWGPositive iron / negative constantan18.5 mm
Multipair screened thermocouple instrumentation cable TX 2 pair 1/0.5 mm solid / 24 AWGTX2 pair1/0.5 mm solid / 24 AWGPositive copper / negative constantan9.3 mm
Multipair screened thermocouple instrumentation cable TX 2 pair 7/0.2 mm stranded / 24 AWGTX2 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan9.5 mm
Multipair screened thermocouple instrumentation cable TX 4 pair 1/0.5 mm solid / 24 AWGTX4 pair1/0.5 mm solid / 24 AWGPositive copper / negative constantan10.8 mm
Multipair screened thermocouple instrumentation cable TX 4 pair 7/0.2 mm stranded / 24 AWGTX4 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan11.0 mm
Multipair screened thermocouple instrumentation cable TX 8 pair 1/0.5 mm solid / 24 AWGTX8 pair1/0.5 mm solid / 24 AWGPositive copper / negative constantan13.0 mm
Multipair screened thermocouple instrumentation cable TX 8 pair 7/0.2 mm stranded / 24 AWGTX8 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan13.1 mm
Multipair screened thermocouple instrumentation cable TX 12 pair 1/0.5 mm solid / 24 AWGTX12 pair1/0.5 mm solid / 24 AWGPositive copper / negative constantan14.7 mm
Multipair screened thermocouple instrumentation cable TX 12 pair 7/0.2 mm stranded / 24 AWGTX12 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan14.8 mm
Multipair screened thermocouple instrumentation cable TX 24 pair 1/0.5 mm solid / 24 AWGTX24 pair1/0.5 mm solid / 24 AWGPositive copper / negative constantan18.4 mm
Multipair screened thermocouple instrumentation cable TX 24 pair 7/0.2 mm stranded / 24 AWGTX24 pair7/0.2 mm stranded / 24 AWGPositive copper / negative constantan18.5 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
