Indoor multipair telephone cable
CW1308 Internal Telecom Cable is a telephone cable reference for indoor telephone systems, pabx wiring, low-level signalling, using class 1 solid annealed copper conductor, pvc pair insulation, screen-free indoor telephone construction and white pvc outer sheath.
Cable Type Data
CW1308 Internal Telecom Cable is a telephone cable reference for indoor telephone systems, pabx wiring, low-level signalling, using class 1 solid annealed copper conductor, pvc pair insulation, screen-free indoor telephone construction and white pvc outer sheath.
Specifications
Each row below is a complete specification sheet — 13 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
Each row is an exact telephone cable cable specification sheet.
| Cable reference | Pair count | Pair / unit construction | OD guide | Weight guide |
|---|---|---|---|---|
| CW1308 internal telecom cable 2 pair 0.5 mm | 2 pair | 1 x 2 twisted pairs | 7.7 mm | 54 kg/km |
| CW1308 internal telecom cable 3 pair 0.5 mm | 3 pair | 1 x 3 twisted pairs | 8.2 mm | 59 kg/km |
| CW1308 internal telecom cable 4 pair 0.5 mm | 4 pair | 1 x 4 twisted pairs | 8.6 mm | 64 kg/km |
| CW1308 internal telecom cable 6 pair 0.5 mm | 6 pair | 1 x 6 twisted pairs | 9.3 mm | 72 kg/km |
| CW1308 internal telecom cable 8 pair 0.5 mm | 8 pair | 1 x 8 twisted pairs | 9.9 mm | 81 kg/km |
| CW1308 internal telecom cable 10 pair 0.5 mm | 10 pair + earth option | 1 x 10 pair unit + earth option | 10.4 mm | 88 kg/km |
| CW1308 internal telecom cable 12 pair 0.5 mm | 12 pair + earth option | 1 x 12 pair unit + earth option | 10.9 mm | 96 kg/km |
| CW1308 internal telecom cable 16 pair 0.5 mm | 16 pair + earth option | 1 x 16 pair unit + earth option | 11.7 mm | 110 kg/km |
| CW1308 internal telecom cable 20 pair 0.5 mm | 20 pair + earth option | 1 x 20 pair unit + earth option | 12.4 mm | 124 kg/km |
| CW1308 internal telecom cable 25 pair 0.5 mm | 25 pair + earth option | 1 x 25 pair unit + earth option | 13.3 mm | 141 kg/km |
| CW1308 internal telecom cable 30 pair 0.5 mm | 30 pair + earth option | 1 x 30 pair unit + earth option | 14.0 mm | 157 kg/km |
| CW1308 internal telecom cable 50 pair 0.5 mm | 50 pair + earth option | 5 x 10 pair units + optional earth wire | 16.5 mm | 220 kg/km |
| CW1308 internal telecom cable 100 pair 0.5 mm | 100 pair + earth option | 10 x 10 pair units + optional earth wire | 21.0 mm | 366 kg/km |
Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
