Category 6 foil screened LAN cable
Cat6 F/UTP LSZH LAN Cable is a structured cabling product for EMI-sensitive building routes, IP surveillance, Wireless access points, using Cat6, 4 x 2 pair, F/UTP shielding and jacket options including LSZH CPR Cca indoor jacket or PVC CMR riser jacket.
Cable Type Data
Cat6 F/UTP LSZH LAN Cable is a structured cabling product for EMI-sensitive building routes, IP surveillance, Wireless access points, using Cat6, 4 x 2 pair, F/UTP shielding and jacket options including LSZH CPR Cca indoor jacket or PVC CMR riser jacket.
Specifications
Each row below is a complete specification sheet — 1 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.
Each row is an exact cable specification sheet. Confirm channel class, installation route, fire rating, shielding, colour, packing length and certification test requirements before quotation.
| Cable reference | Category | Pair layout | Conductor | Bandwidth | Transmission | Shielding | Jacket / rating | Power support | Max DC resistance at 20 °C | OD guide |
|---|---|---|---|---|---|---|---|---|---|---|
| Cat6 F/UTP LAN Cat6 4 x 2 pair AWG23/1 solid bare copper F/UTP PVC CMR riser jacket | Cat6 | 4 x 2 pair | AWG23/1 solid bare copper | 250 MHz | 1 Gbit/s to 100 m; 10 Gbit/s for short channel design | F/UTP | PVC CMR riser jacket | PoE / PoE+ / PoE++ with screen bonding | 7.6 Ω/100 m max | 6.6 mm |
Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
