Outdoor Cat6A F/UTP PE LAN Cable cable construction reference

Outdoor and campus LAN cable

Outdoor Cat6A F/UTP PE LAN Cable

Outdoor Cat6A F/UTP PE LAN Cable is a structured cabling product for Campus links, Outdoor IP cameras, Wireless access points, using Cat6A, 4 x 2 pair, F/UTP shielding and jacket options including UV resistant PE outdoor jacket or Direct burial PE jacket.

Standard
IEC 61156-5
Conductor
AWG23/1 solid bare copper
Insulation / jacket
UV resistant PE outdoor jacket / Direct burial PE jacket
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Outdoor Cat6A F/UTP PE LAN Cable is a structured cabling product for Campus links, Outdoor IP cameras, Wireless access points, using Cat6A, 4 x 2 pair, F/UTP shielding and jacket options including UV resistant PE outdoor jacket or Direct burial PE jacket.

  • Campus links
  • Outdoor IP cameras
  • Wireless access points
  • Building-to-building Ethernet

Cable Construction

  • AWG23/1 solid bare copper
  • Four balanced twisted pairs
  • PE pair insulation with category-controlled twist lay
  • F/UTP
  • UV resistant PE outdoor jacket or Direct burial PE jacket

Specifications

Select a cable size.

Each row below is a complete specification sheet — 2 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Cat6A structured cabling references

Each row is an exact cable specification sheet. Confirm channel class, installation route, fire rating, shielding, colour, packing length and certification test requirements before quotation.

  • CategoryCat6A
  • Pair layout4 x 2 pair
  • ConductorAWG23/1 solid bare copper
  • Bandwidth500 MHz
  • Transmission10 Gbit/s up to 100 m channel design
  • ShieldingF/UTP
  • Power supportPoE / PoE+ / PoE++ with outdoor route review
  • Max DC resistance at 20 °C7.6 Ω/100 m max
  • OD guide8.3 mm
Cable referenceJacket / rating
Outdoor Cat6A F/UTP LAN Cat6A 4 x 2 pair AWG23/1 solid bare copper F/UTP UV resistant PE outdoor jacketUV resistant PE outdoor jacket
Outdoor Cat6A F/UTP LAN Cat6A 4 x 2 pair AWG23/1 solid bare copper F/UTP Direct burial PE jacketDirect burial PE jacket
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.

Request Quote →
