BS 6724 XLPE SWA LSZH Armoured Cable cable construction reference

Armoured LSZH power cable

BS 6724 XLPE SWA LSZH Armoured Cable

BS 6724 XLPE SWA LSZH Armoured Cable is a specific low smoke zero halogen cable construction for public buildings, transport infrastructure, industrial feeders, using class 2 copper conductor, xlpe insulation, steel wire armour and lszh outer sheath.

Standard
BS 6724
Voltage class
0.6/1 kV
Conductor
Class 2 copper conductor
Insulation / jacket
LSZH outer sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

BS 6724 XLPE SWA LSZH Armoured Cable is a specific low smoke zero halogen cable construction for public buildings, transport infrastructure, industrial feeders, using class 2 copper conductor, xlpe insulation, steel wire armour and lszh outer sheath.

  • Public buildings
  • Transport infrastructure
  • Industrial feeders
  • Direct burial with fire-safety requirement

Cable Construction

  • Class 2 copper conductor
  • XLPE insulation
  • Steel wire armour
  • LSZH outer sheath
  • Low smoke zero halogen compound system

Specifications

Select a cable size.

Each row below is a complete specification sheet — 55 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Armoured power distribution specification references

Each row is an exact LSZH cable specification sheet. Shared fire behavior, insulation, screen/protection and sheath data are listed above.

  • Voltage class0.6/1 kV
  • Cable useArmoured power distribution
  • Fire behaviorLow smoke, zero halogen armoured cable for public and infrastructure routes
Cable referenceCore / pair designConductor sizeMax DC resistance at 20 °COD guide
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 1.5 mm²2C1.5 mm²12.1 Ω/km19 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 2.5 mm²2C2.5 mm²7.41 Ω/km20 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 4 mm²2C4 mm²4.61 Ω/km20 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 6 mm²2C6 mm²3.08 Ω/km21 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 10 mm²2C10 mm²1.83 Ω/km23 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 16 mm²2C16 mm²1.15 Ω/km25 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 25 mm²2C25 mm²0.727 Ω/km27 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 35 mm²2C35 mm²0.524 Ω/km28 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 50 mm²2C50 mm²0.387 Ω/km31 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 70 mm²2C70 mm²0.268 Ω/km33 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 95 mm²2C95 mm²0.193 Ω/km36 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 120 mm²2C120 mm²0.153 Ω/km39 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 150 mm²2C150 mm²0.124 Ω/km41 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 185 mm²2C185 mm²0.0991 Ω/km44 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 2C 240 mm²2C240 mm²0.0754 Ω/km48 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 1.5 mm²3C1.5 mm²12.1 Ω/km19 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 2.5 mm²3C2.5 mm²7.41 Ω/km20 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 4 mm²3C4 mm²4.61 Ω/km21 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 6 mm²3C6 mm²3.08 Ω/km22 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 10 mm²3C10 mm²1.83 Ω/km23 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 16 mm²3C16 mm²1.15 Ω/km25 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 25 mm²3C25 mm²0.727 Ω/km27 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 35 mm²3C35 mm²0.524 Ω/km29 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 50 mm²3C50 mm²0.387 Ω/km31 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 70 mm²3C70 mm²0.268 Ω/km34 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 95 mm²3C95 mm²0.193 Ω/km37 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 120 mm²3C120 mm²0.153 Ω/km39 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 150 mm²3C150 mm²0.124 Ω/km42 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 185 mm²3C185 mm²0.0991 Ω/km45 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 3C 240 mm²3C240 mm²0.0754 Ω/km49 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 1.5 mm²4C1.5 mm²12.1 Ω/km20 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 2.5 mm²4C2.5 mm²7.41 Ω/km21 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 4 mm²4C4 mm²4.61 Ω/km21 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 6 mm²4C6 mm²3.08 Ω/km22 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 10 mm²4C10 mm²1.83 Ω/km24 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 16 mm²4C16 mm²1.15 Ω/km26 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 25 mm²4C25 mm²0.727 Ω/km28 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 35 mm²4C35 mm²0.524 Ω/km29 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 50 mm²4C50 mm²0.387 Ω/km32 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 70 mm²4C70 mm²0.268 Ω/km34 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 95 mm²4C95 mm²0.193 Ω/km37 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 120 mm²4C120 mm²0.153 Ω/km40 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 150 mm²4C150 mm²0.124 Ω/km42 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 185 mm²4C185 mm²0.0991 Ω/km45 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 4C 240 mm²4C240 mm²0.0754 Ω/km49 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 1.5 mm²5C1.5 mm²12.1 Ω/km20 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 2.5 mm²5C2.5 mm²7.41 Ω/km21 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 4 mm²5C4 mm²4.61 Ω/km22 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 6 mm²5C6 mm²3.08 Ω/km23 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 10 mm²5C10 mm²1.83 Ω/km24 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 16 mm²5C16 mm²1.15 Ω/km26 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 25 mm²5C25 mm²0.727 Ω/km28 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 35 mm²5C35 mm²0.524 Ω/km30 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 50 mm²5C50 mm²0.387 Ω/km32 mm
BS 6724 XLPE SWA LSZH 0.6/1 kV Armoured power distribution 5C 70 mm²5C70 mm²0.268 Ω/km35 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
