Submarine Outboard Pressure Resistant Cable cable construction reference

Pressure-resistant submarine cable

Submarine Outboard Pressure Resistant Cable

Submarine Outboard Pressure Resistant Cable is a defence cable construction for submarine systems, underwater defence equipment, outboard sensors, using tinned copper conductor, water-blocked defence insulation, water-blocked braid screen and pressure-resistant jacket and pressure-resistant polyurethane or special elastomer sheath.

Standard
VG 95218 style reference
Voltage class
Signal and control circuit
Conductor
Tinned copper conductor
Insulation / jacket
Pressure-resistant polyurethane or special elastomer sheath
Download PDF ↓ Request Quote →

Cable Type Data

Construction and applications.

Applications

Submarine Outboard Pressure Resistant Cable is a defence cable construction for submarine systems, underwater defence equipment, outboard sensors, using tinned copper conductor, water-blocked defence insulation, water-blocked braid screen and pressure-resistant jacket and pressure-resistant polyurethane or special elastomer sheath.

  • Submarine systems
  • Underwater defence equipment
  • Outboard sensors
  • Naval communication

Cable Construction

  • Tinned copper conductor
  • Water-blocked defence insulation
  • Water-blocked braid screen and pressure-resistant jacket
  • Pressure-resistant polyurethane or special elastomer sheath
  • Pressure-resistant, water-blocked and salt-water duty

Specifications

Select a cable size.

Each row below is a complete specification sheet — 9 sizes in total. Click any row to open conductor data, resistance, dimensions, weight and ordering reference.

Submarine and outboard defence cable references

Each row is an exact defence cable cable specification sheet. Shared mission environment, materials and documentation logic are listed above.

  • Mission dutySubmarine outboard and pressure-resistant system
  • PlatformSubmarine and underwater defence equipment
  • Shield / protectionWater-blocked braid screen and pressure-resistant jacket
  • Environment classPressure-resistant, water-blocked and salt-water duty
Cable referenceCable designConductor / fibreElectrical referenceOD guide
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 2 core pressure-rated 0.5 mm²2 core pressure-rated0.5 mm²39.0 Ω/km conductor resistance13.6 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 2 core pressure-rated 1.0 mm²2 core pressure-rated1.0 mm²18.5 Ω/km conductor resistance14.2 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 2 core pressure-rated 1.5 mm²2 core pressure-rated1.5 mm²13.3 Ω/km conductor resistance14.6 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 core pressure-rated 0.5 mm²4 core pressure-rated0.5 mm²39.0 Ω/km conductor resistance14.4 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 core pressure-rated 1.0 mm²4 core pressure-rated1.0 mm²18.5 Ω/km conductor resistance15.0 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 core pressure-rated 1.5 mm²4 core pressure-rated1.5 mm²13.3 Ω/km conductor resistance15.4 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 pair pressure-rated 0.5 mm²4 pair pressure-rated0.5 mm²39.0 Ω/km conductor resistance15.6 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 pair pressure-rated 1.0 mm²4 pair pressure-rated1.0 mm²18.5 Ω/km conductor resistance16.2 mm
Submarine outboard pressure resistant cable Submarine outboard and pressure-resistant system Submarine and underwater defence equipment 4 pair pressure-rated 1.5 mm²4 pair pressure-rated1.5 mm²13.3 Ω/km conductor resistance16.6 mm
Cable Specification Sheets Exact cable references by conductor size and construction.

Specification sheets include conductor material, size, resistance, diameter, weight, construction and quotation reference.
